HIGHLEAD GG0328-1 Walking Foot Zig Zag Sewing Machine for Leather and Heavy Fabrics


HIGHLEAD GG0328-1 Walking Foot Zig Zag Sewing Machine for Leather and Heavy Fabrics


HIGHLEAD GG0328-1 Walking Foot Zig Zag Industrial Sewing Machine for Leather, Vinyl, Webbing, Canvas and Other Heavy Materials

  • Description
  • Reviews (0)


Machine Brand MACHINE BRAND: HIGHLEAD Sewing Machines
Sewing Machine Model MACHINE MODEL:


Sewing Machine Description MACHINE DESCRIPTION:

A wide range of sewing threads can be used, with the GG0328-1 being able to sew with up-to size 20* synthetic thread (or size 30 cotton thread) + V46, V69, V92 & V138* bonded nylon heavy duty threads etc.

This Highlead model employs a parallel vertical needle bar motion for stronger striking power and a semi-automatic lubrication system which can reduce servicing costs.

A large Zigzag width of up-to 10mm + a stitch length of up-to 5mm is available and fully adjustable by the operator.

The GG0328-1 model also has the option to sew with a straight style stitch by setting the zigzag width to zero.

The sewing hook & base containing the lower bobbin is twice the normal size, resulting in less bobbin changes, which is of particular use when using thicker than normal threads.

Highlead GG0328-1 industrial zigzag sewing machine can be used on Sails, leather goods, bags, canvas/plastic, handbags, nets, bandages, straps, Velcro, Neoprene, body supports etc.


If you are not familiar with HIGHLEAD yet, it is a “TIER 1” Chinese manufacturer with ISO-9001 quality standards, a winner of multiple quality manufacturing awards and a contractor for MITSUBISHI Automation.  This is a GOOD, QUALITY sewing machine brand with many years of proven track record in the American market.


Techical Specifications TECHNICAL SPECS:
  • Max sewing speed: 1800rpm
  • Stitch length: 0-5mm
  • Zigzag width 0-10mm
  • Needle bar stroke: 36mm
  • Take up stroke: 82mm
  • Presser foot lift by hand: 7mm
  • Presser foot lift by knee: 12mm
  • Working space: 260mm x 115mm
  • Needle size: DPx35 size 100 to 140


Sewing Machine Setup MACHINE SETUP: This machine ships complete and fully assembled – ready to sew upon arrival.

It includes:

  • Machine Head
  • Table Top
  • Heavy Duty Stand
  • SERVO Motor
  • Thread Stand
  • LED Light
  • Manuals
  • Extra needles, bobbins, and tools.


Sewing Machine Voltage MOTOR & VOLTAGE: This machine is equiped with a SERVO motor operating on standard 110 Volts power.
Sewing Machine Warranty WARRANTY: 1 Year Warranty
Sewing Machine Sale Price SALE PRICE: $2,795.00
Sewing Machine Shipping Cost SHIPPING COST: Commercial / Business Address = please call us for pricing

Home / Residential Address = please call us for pricing

Delivery Time DELIVERY TIME: In stock.  4 to 5 days delivery window.
